Thursday, July 1, 2010

Shirt Sleeve Placket

The Book says, “A Shirt Sleeve Placket is usually inserted into a…tailored shirt or jacket sleeve while the sleeve is still flat and before it is sewn into the garment.”   This is the type of placket I found the most of around my house, but it takes a few steps to complete.

IMG_7475
In addition to the sleeve piece (again, mine here is a crude one I just free cut out for the lesson), you’ll need a top placket piece that has two peaks and is two wide long by twice the desired length of the placket opening.  Also an under placket 1.5 inches wide by the length of the desired placket opening
IMG_7447



On the sleeve itself, cut an opening with a 1/4 inch stitchline.  I marked in black the basic way it needs to be cut, like an inverted arrow.IMG_7449IMG_7454

Flip the sleeve so the wrong side is facing up.  Take the under placket piece, wrong side facing up, and place it at the right side of the opening, lining up the left edge of the under placket with the right edge of the opening.  Stitch the length of the under placketIMG_7451
Press the unsewn side of the under placket, the right side, over 1/4 inch to the wrong side
IMG_7453

Now flip the whole sleeve piece over.  Pull the under placket out
IMG_7455

Fold the under placket to the right side of the fabric, covering up the [now] left side of the placket opening, as you would if binding
IMG_7456

Sew in place the length of the opening, 1/4 inch in

IMG_7457

Flip the sleeve and finished under placket back, exposing the very top of the under placket and the little inverted arrow point/snipped triangle at the top of the opening.

 IMG_7460            IMG_7458
Stitch across, catching both the under placket top and the triangle
IMG_7461IMG_7462

Now it’s time to prepare the top placket

IMG_7463

Fold, right sides together, along the length and sew from the inside fold of at the base of the peak, up around the peak itself and then back down to the half way point.  The unsewn length needs to be equal to the length of the placket opening.

IMG_7464

Clip, turn, push out corners

IMG_7465

So now you’ll have that raw edge length down at the bottom. Clip the top of the opened area to the stitch line on the bottom side

  IMG_7467
Match that bottom raw edge side to the raw edge of the sleeve placket, on the wrong side of the fabric

IMG_7468

Sew in place the length of the placket opening, NOT the length of the entire top placket

IMG_7469

Flip to the other side

IMG_7470

And press under the remaining raw top placket length 1/4 inch

IMG_7471

Pin the top of the placket in place

IMG_7472

And do a fun little top stitch around the entire top, reinforcing near the bottom with a little rectangle of topstitch fun

IMG_7473

Now, moving the other side of the placket out of the way, sew the top placket to the remaining length of the placket

 IMG_7474

Add a cuff and call it a sleeve

    IMG_7475
